36v 350watt cycle hub motor controller

Name: 36v 350watt cycle hub motor controller
SKU: 2815
Price: 1200.00 INR
Availability: InStock

Original price was: ₹1,500.00.Current price is: ₹1,200.00.

& Free Shipping

Product Overview

This premium quality 36V 350W Brushless DC (BLDC) Motor Controller is engineered specifically for electric bicycles and e-scooters. Crafted with a durable aluminum alloy shell, it ensures efficient heat dissipation, protecting internal circuitry from overheating and extending the overall lifespan of your e-bike system.

Technical Specifications

- Brand / Series: STARBLUE (Star-Electric Solutions)
- Rated Voltage: 36V DC
- Rated Power: 350 Watts
- Maximum Current: 13A – 15A
- Under-Voltage Protection: 31.5V ± 0.5V (Prevents over-discharging and protects battery life)
- Throttle Input Voltage: 1.1V – 4.2V
- Brake Input: Low-Level / High-Level (Automatic motor power cut-off)
- Phase Angle: 60° / 120° Self-Identification (Dual-Mode compatible)
- Waterproof Rating: IPX5 (Splash and rain-resistant)
- Casing Material: High-Grade Aluminium Alloy with Grooved Heat Sink

Key Features

- Dual Mode Functionality: Automatically detects and operates smoothly with both Hall-Sensor and Sensorless BLDC hub motors.
- Intelligent Safety Protection: Built-in over-current, under-voltage, and anti-coastal protection to secure the motor against sudden voltage spikes.
- Silent & Smooth Operation: Advanced sine-wave/square-wave logic reduces motor noise and provides steady acceleration.
- Plug-and-Play Design: Standardized color-coded bullet and block connectors for hassle-free DIY installation.

Wiring Reference Guide

1. Power Supply: Heavy Red (Positive +), Heavy Black (Negative -)
2. Motor Phase: Heavy Blue, Heavy Green, Heavy Yellow
3. Hall Sensor: 5-Wire Connector (Red, Black, Blue, Green, Yellow)
4. Throttle: 3-Wire Connector (Red, Black, Green/White)
5. Electric Door Lock (Ignition): Single Thin Red or Orange wire
6. Brake Lever: 2-Wire Connector (Signal cut-off)
7. Pedal Assist System (PAS): 3-Pin Sensor Input
